Location: Home > 產品及技術
液晶顯示模塊
Application Area
Product Specification

LCM

Technical Specifications:

? LCD Type: TN, HTN, STN, FSTN, positive mode

? Background Color: blue, yellow/green, grey

? Display Mode: Transmissive, reflective, transflective

? Viewing Direction: 6 o'clock or 12 o'clock

? Number Of Dots: 8*1 ~ 320*240 or on request

? Polarizer Type: general durability, medium durability, high durability

? Typical Thickness: 1.1mm or on request

? Driver Method: 1/4 duty, 1/3 bias or on request

? Operating Voltage: 2.7V~5.0V 64Hz

? Operating Temperature: -20~+70; -30~+80; -40~+85

? Connector: Pin, any length is available



Model Type:
